TAPPING OF MATERIALS WITH M30
- KG/MM²: 120
- BRINELL: 352
- ROCKWELL HRC: 37
TAPPING CAPACITY
- METRIC: M2-M30
- INCHES: BSW 3/32 - 1" 1/8
- BSP 1/16 - 1" 1/8
TECHNICAL CHARACTERISTICS
- CAPACITY: M2-M30
- R.P.M.: 22 a 630
- MAXIMUM PRESSURE: 140 Kg /cm²
- MOTOR 3 PS / 2.2KW
- VOLTAGE 400V-III-50HZ
- SPEED CONTROL: ELECTRONIC
- SLIDING BARS LENGTH: 750 mm
- TABLE WORKAREA: TOTAL
- QUICK CHANGE CHUCK: Nº 2 31mm
- OIL TANK: 50 LITROS
- WEIGHT: 450 Kg
SERIAL EQUIPMENT
- ARTICULATED ARM: 3 BARS
- T-SLOT TABLE: 900 X 630 m
- DIGITAL SPEED INDICATOR (R.P.M.)
- COMPLETE HYDRAULIC GROUP
- TAP-HOLDER SIDE SHELF
- PRESSURE MANOMETER PROTECTION KEY
- HYDRAULIC PRESSURE REGULATION GAUGE
- POSITIONING DEVICE FOR HORIZONTAL TAPPING
Send Inquiry
